ML7038 Multipoint thermocouple and Pt100

ML7038 Multipoint thermocouple and Pt100

ML7038
true
Design
Designed to measure temperatures on serveral levels in reactor vessels, Petroleum refining processes, Waste oil distillation to diesel, catalyst beds and many others
true
Model
Model ML 7038
true
Protection tube
Construction
Closed-end tube
Material
Customer to specify
Process connection
Flanged ( Optional threaded )
Material
Customer to specify, examples are SS316, SS310, SS321, SS347, Inconel 600 and many others
Flange type
Customer to specify
true
Connection box
Type
Weatherproof IP 65
Material
Polyester, Stainless steel, or coated aluminium
Cable entry
One or more
Construction
Standard or explosionproof to ATEX or IECEX Exe, Exi or Exd
true
Extension
Type
Nipple - union - nipple, fixed pressure/containment chamber or fixed length tube
Material
Meeting the material of the protection tube applied
true
Elements
Type
Mineral insulated single or duplex sensing element
Positions L1 to Ln
Customer to specify
Thermocouple
K, T, J, E, N, U or L
Pt100
Vibration proof Superior class Pt100 detectors
true
Accuracy
Thermocouples
According IEC 60584
Pt100
Class A or B according to IEC 60751
true
Construction
Several measuring constructions are possible, see separate datasheets
true
Datasheet notifications
true
true
This datasheet is purely indicative, build-up of model code may vary from this datasheet

Customisation possibilities

You can remark the customisation in your quote

PRODUCTCODE

ML7038
