SW 3020 Threaded thermowell – tapered

SW 3020 Threaded thermowell – tapered

SW 3020
true
Thermowell
Design
Drilled bar stock (solid machined)
Process connection
Male threaded
Thread size
1/2"NPT, 1/2"BSP (G1/2"), M20x1.5, M24x1.5 or other threads possible
Material
SS 316 - (Wst 1.4401) standard, other materials possible
true
Stem / Shaft
Wetted part
Tapered, see table
Insertion length
To specify
Bore Size
6.5 mm standard
Excentricity
<1 micrometer
Bottom thickness
5 mm standard
true
Connection length
Standard length
50mm
Extended Hexagon
To specify
true
Female connection
Threaded
1/2"NPT, 1/2"BSP (G1/2"), M20x1.5, M24x1.5 or other threads possible
Other thread size
To specify
true
Options
Other materials and dimensions
Plug and chain for test wells
Protective coating; PTFE, Halar, Stellite etc.
Tagging
Wake frequency calculation

Customisation possibilities

You can remark the customisation in your quote

PRODUCTCODE

SW 3020
Process connection

"U" length in mm

"X" length in mm
