MBA Bearing shoe thermocouple sensor 3.2 x 8mm

MBA Bearing shoe thermocouple sensor 3.2 x 8mm

MBA
true
Application
A range of high accuracy miniature embedded (also known as embedment) thermocouple sensors designed for surface temperature measurements in general industrial applications such as in bearing shoe applications to give a reliable indication of bearing wear and oil film breakdown through continuous monitoring of temperature. These tip sensitive thermocouples have an operating temperature range of -25°C to +250°C and can be supplied with a pressure tested oil seal barrier to prevent leakage. Standard assemblies are easy to install in drilled holes for general temperature sensing applications, whereas the spring loaded ‘top hat’ style assemblies are inserted into a milled hole with a retaining clip pushed down to compress the spring and retain the sensor against the surface being monitored.
true
Sensor
Thermocouple type
K, T, J, N or E
Duplex type
KK, TT, JJ, NN or EE
Accuracy
According to IEC 60584
Operating range
-25°C up to +250°C
Material
Stainless steel or phosphor bronze
Diameter
1.5, 2.0, 3.0, 3.2, 4.0, 6.0 or 6.35mm
Length simplex sensor
8.0mm standard, or contact us to specify
Length duplex sensor
12mm standard, or contact us to specify
true
Cable
Twisted wires with external armour
PFA insulated twisted wires with stainless steel braiding (TA)
Cable with external armour
PFA cable jacket with external Stainless steel braiding (TTA)
Length
1000mm standard, other lengths possible
Colourcode
IEC
true
Options
Explosion proof versions
ATEX / IECEx versions available, please consult us
Oil seal part
Standard 60 x 4.75mm
Other dimensions
Please consult us

Customisation possibilities

You can remark the customisation in your quote

PRODUCTCODE

MBA
Thermocouple type

Cable type TA or TTA

Colourcode

Cable length
